CCTV Tester, IPC-5200C Plus 5 Inch IPS Touch Screen IP CVBS Analog Camera Tester 4K H.265 Video Monitor with HDMI Input/POE/WiFi/Cable Tracker/TVI CVI AHD/Firmware Upgraded
£319.00
Price: £319.00
(as of Nov 14, 2025 06:14:05 UTC – Details)
Product Description
Add To Basket
Add To Basket
Add To Basket
Add To Basket
Customer Reviews
4.0 out of 5 stars 75
—
3.8 out of 5 stars 127
4.7 out of 5 stars 3
5.0 out of 5 stars 2
3.0 out of 5 stars 1
Price
£319.00£319.00
— no data
£109.00£109.00 £213.00£213.00
— no data
£759.00£759.00
screen size
5 inch IPS touch screen, 1920×1080 resolution 4 inch IPS touch screen , 800*480 resolution 5inch 4 inch IPS touch screen , 960*640 resolution 7 inch IPS touch screen, 1920*1200 resolution 8 inch touch screen with retina display ,2048*1536 resolution
IPC camera test
✓
✓
no data
✓
✓
✓
8MP AHD camera test
✓
✓
✓
✓
✓
✓
8MP TVI camera test
✓
✓
✓
✓
✓
✓
8MP CVI camera test
✓
✓
✓
✓
✓
✓
HD-SDI/3G-SDI/EX-SDI*
✓
no data
no data
no data
✓
✓
DC power output
DC12V 3A DC12V 3A DC12V 1A DC12V 3A DC12V 3A DC12V 3A
POE power output
48V 48V no data
48V 48V 48V
HDMI input
✓
no data
✓
no data
✓
✓
HDMI output
no data
no data
no data
no data
✓
✓
IPC5200C IPC CCTV tester monitor
12MP IPC Tester 8MP/AHD/CVI/TV/SDI CCTV Tester with HDMI VGA Input CCTV Monitor for IP Camera Tester CCTV Tester CCTV
Application
The 5 inch IPS touch screen IP camera tester is designed for maintenance and installation of IP analog, HD coaxial cameras as well as other security equipment. The 1920*1080 resolution enables it to display network HD cameras and analog cameras in high resolution.
The unit supports many O** PTZ and analog PTZ control, and cable test functions. CCTV installers often need to carry a variety of testing tools to complete their work. If take the all in one camera tester, making working conditions safer and increasing productivity.
CCTV system installation and maintenance
Network cabling project installation and maintenance
Dome camera, IP TVI CVI AHD SDI 4K H.265 camera testing
Video transmission channel testing
PTZ controller
8MP TVI camera test, 3840 x 2160P 12.5/15 FPS, UTC control/ call OSD menu
8MP CVI camera test, 3840 x 2160P 12.5/15 FPS, UTC control / call OSD menu
8MP AHD test, 3840 x 2160P 15FPS, UTC control / call OSD menu
8MP EX-SDI, HD-SDI, 3G-SDI, UTC control / call OSD menu *
Auto HD app, auto recognize HD coax camera type and resolution, support snapshot, video record& playback, coaxial PTZ & call OSD menu
● Rapid O**, Auto log in and display image, create testing report
● IPC TEST (Non-O** test), HIK test tool , DH test tool
IPC CCTV tester monitor Feature
IPC CCTV tester monitor Feature
Feature
● 5 inch IPS touch screen, 1920×1080 resolution
● 8MP CVI/ TVI/ AHD camera test
● 8MP EX-SDI, HD-SDI, 3G-SDI camera test
● H.265/H.264, 4K video display via mainstream
● VGA input, support 2048 x 1152 60FPS
● HDMI Input, support 4K 30FPS
● DC12V 3A, 48V PoE power output
● Rapid O**, Create the test report and modify IP address, etc
● Auto HD, auto recognize HD coax camera type and resolution
● RJ45 TDR cable test, cable quality test
● UTP cable test, detect the near-end, mid-end and far-end fault point of the network cable crystal head
IP Tester Sytem Languages Optional
English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese, Deutsch, Turkish, Portuguese, Czech
IPC tester pro
IPC tester pro
IP Discovery/Quick O**/IPC test /RTSP play / Client APK
Rapid Video
Auto view the video, create testing report
HIK test tool
Support batch activate HIK cameras and modify IP address, modify password etc. Self-defined modify channel name, can quickly change H.264 and H.265 video, open wide dynamic mode. Factory restore, etc.
DH test tool
Support batch activate DH cameras and modify IP address, username and password. Self-defined modify channel name.
UTP cable test
Test UTP cable connection status and display on the screen. Can detect the near-end, mid-end and far-end fault point of the RJ45 cable plug
RJ45 TDR cable test
Test cable pair status, length, attenuation, reflectivity, impedance, skew, can create test report. measurement range 180M
cctv tester monitor
online update
Support local update, online update, support to install your own APP
Other Functions
● Network tool: Ping, IP scan, Port Flash, DHCP server, Trace Route
● Tester Play: Tester, android version mobile phone and PC display at the same time
● Traffic monitoring, display network port or WIFI connection real-time upload and download speeds and other network parameters
● Customers self-update software, you can install apps with android version
● Media player, 4K video files and MKV/MP4 media files play
● Display its genuine resolution of the IP camera images
cable tracker
Search BNC cable, network cable and telephone cable from the mess cables. Cable search and UTP cable can test at the same time
12V/3A power and POE 48V
Output DC12V/3A power out, supply temporarily power for the camera
PoE power output
48V PoE power output, max power 25.5W
● 7.4 V /3350mAh Lithium Ion Polymer Battery, after 3-4 hours charging, working time lasts 5 hours
● Audio in, support record and save the audio/LED lamp, calculators, music players and other application tools
HDMI input for CCTV tester monitor
IPC CCTV tester monitor
VGA input, up to 2048 x 1152 60FPS, support snapshot, video record & playback
1 channel VGA input, support 2048 x 1152 60FPS. The resolution as follow: 2048 x 1152P/ 1920 x 1200P 60FPS/1920×1080P 60FPS /1792×1344P 60FPS /1680x 1050P 60FPS/(1600x1200P/900P 60FPS)/1440x900P 60FPS/1360x768P 60FPS/(1280×1024/960/800/768/720P 60FPS)/1152x870P 60FPS/1024x768P 60FPS/800x600P 60FPS/600x480P 60FPS
HDMI Input, up to 4K 30FPS, support snapshot, video record & playback
1 channel HDMI input, support 4K 30FPS. The resolution as follow: 4K_3840 x 2160/2K_2560 x 1440P/
1920×1080P /1920×1080i /720×480P /720×576P /1280×720P/1024×768P/1280×1024P /1280×900P /1440×900P, etc
other :
Auto HD app, auto recognize HD coax camera type and resolution, support snapshot, video record & playback, coaxial PTZ & call OSD menu.
● Rapid video, just by one key to detect all network cameras and auto display
● Built in Wi-Fi, display image from the wireless camera, create WIFI hotspot
Model : IPC CCTV tester monitor 5200C plus
Display New 5 inch IPS touch screen, 1920×1080 resolution CVBS camera test 1 channel BNC input, NTSC/PAL (Auto adapt) PTZ control, RS485 control, Baud 600-115200bps, compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic etc 12V/3A power output Output DC12V/3A power out, supply temporarily power for the camera PoE power output 48V PoE power output, max power 25.5W IP camera test 4K/H.265/H.264 , IP Discovery/Quick O***/IPC test /RTSP play / Client APK HDMI input 1 channel HDMI input, support 4K 30FPS. The resolution as follow: 4K_3840 x 2160/2K_2560 x 1440P/ 1920×1080P /1920×1080i /720×480P /720×576P /1280×720P/1024×768P/1280×1024P /1280×900P /1440×900P, e HD Coaxial test * 8MP AHD /TVI /CVI camera test CVBS PTZ control, RS485 control, Baud 600-115200bps, compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic etc TesterPlay Screen projection: Tester, mobile phone and PC display at the same time (For android version mobile phone) Network test Trace route, Link monitor, DHCP server, port flashing, Ping test Wi-Fi Built in WIFI, speeds 150M, display wireless camera image Operation setting OSD menu, select your desired language: English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese, Deutsch, Turkish, Portuguese, Czech etc Battery Built-in Lithium ion battery,After charging 3-4 hours, normal working time 6 hours Power management Display DC 12V input & output voltage and power in real time Audio test 1 channel audio signal input, test whether sound normal Data monitor Captures and analyzes the command data from controlling device, also can send hexadecimal
【CCTV Monitor Support 8MP AHD TVI CVI Tester,HDMI/ VGA input ,SDI test, Cable Tracer 】 8MP TVI test, 3840 x 2160P 12.5/15 FPS, 4xzoom, video record & playback, coaxial PTZ control & call OSD menu./ 8MP AHD test, 3840 x 2160P 15 FPS, 4xzoom, video record & playback, coaxial PTZ & call OSD menu ./ 8MP CVI test, 3840 x 2160P 12.5/15FPS, 4xzoom, video record & playback, coaxial PTZ & call OSD menu. / DC12V/3A power output, camera can be powered from DC 12 Voltage.
【 5-In-1 Multifunction CCTV Moniotr Displays】This CCTV camera monitor have 5 inch IPS touch screen, 1920*1080 resolution. it is support H.265 & H .264 IP, 4K video display via mainstream. this monitor support Analog camera test, PTZ controller, support Auto HD app, auto recognize HD coax camera type and resolution, support snapshot, video record & playback, coaxial PTZ & call OSD menu, this cctv moniotor Built in Wi-Fi, display image from the wireless camera, create WIFI hotspot.
【CCTV Moniotr 】 Rapid , Auto log in and display image, create testing report. / IPC test pro, auto scan all network segments IP, auto open PoE power and display the power. Input username and password, can scan camera image, can batch activate use for HIK camera and Dahua cameras. Jump to interface and test tools./ IP and analog display image at the same time.
【Use for HIK Test Tool, Dahua Test Tool】 Use for HIK test tool, support batch activate Use for HIK cameras and modify IP address, modify password etc. Self-defined modify channel name, can quickly change H.264 and H.265 video, open wide dynamic mode. Factory restore, etc. / Dahua test tool, support batch activate DAHUA cameras and modify IP address, user name and password. Self-defined modify channel name. / Rapid video, just by one key to detect all network cameras and auto display.
【Cable Test of This CCTV Tester 】 Improvement cable tester, UTP cable, telephone cable etc order and connectivity test, can save testing report, if special number, need customized. Can detect the near-end, mid-end and far-end fault point of the RJ45 cable plug / RJ45 TDR cable test, test cable pair status, length, attenuation, reflectivity, impedance, skew etc, can create test report.This IPC CCTV AHD TVI CVI CVBS camera tester use for CCTV system installation and maintenance.
10 reviews for CCTV Tester, IPC-5200C Plus 5 Inch IPS Touch Screen IP CVBS Analog Camera Tester 4K H.265 Video Monitor with HDMI Input/POE/WiFi/Cable Tracker/TVI CVI AHD/Firmware Upgraded
Add a review
Related Products
£319.00
Rob G –
Product and customer service from seller has been absolutely superb!
I purchased this device in March 2022. My colleague and I are responsible for numerous businesses which house hundreds of cctv cameras as well as hundreds of networked devices in nightclubs, hotel, bars and commercial premises. During routine maintenance and problem solving we use this device every day to trace network cables, test networks, fault find cameras and cables. The tool is a god send. It makes anything to do with cameras and networks much more straightforward. Our server room has approximately 400 network cables in to various switches and routers and without this tool weâd be desperately stuck as previous installers have not labelled or identified anything plugged in.In May 2023 to my horror I turned on the device one morning and nothing happened and device would not start. I contacted the seller through Amazon and the seller arranged for me to send the unit back to be repaired, even though the device was two months out of the year warranty. The device was returned pretty swiftly and working perfectly againThe device itself is one of my most valued tools in my kit, the customer service from the seller has given me even more confidence in the product and would not hesitate to recommend it to anyone considering buyingI would give 6âï¸ but only allowed to rate 5!!
Eva Marie –
Great product
Great product
Gregory Vandromme –
Already solved a cctv mystery in a single day
As a product, itâs great, all be it with some random Chinese software for that I cannot find a way to change into English soHave just deleted. The rest of the product is just as described. However the price of this product is a large markup from the original price by the manufacturer on Ali express. At almost 100£ markup, if you are just buying a single unit. Probably more as a result of bulk buying discounts. You are paying over a hundred pounds for fast shipping as the Ali express models take a week or two. I decided that it was worth it as it could and did help me solve an issue at a job and it has already paid for itself. But if you want to find the cheaper model on Ali express and donât mind the slow shipping then just search for âipc testerâ and you will find hundreds of this kind of product and some the exact same
“paulcdb” –
Doesnât support 3G-SDI as various sites claim
Iâve tested one of these and it only supports HD-SDI!Also, if you look closely at some of the pictures, it only mentions HD-SDI on the actual port. So sadly returned and time to look for another that does offer what the description says!
Arik –
Chinese buble
does not work at all. I couldn’t even put it on. RUBBISH !!!
Andreas Hofmann –
Ansich ein super Gerät aber ein groÃes und wichtiges Defizit keine WLAN WPA2/3 Unterstützung gerät daher nicht updatebar zurück geschickt
Marco –
Sono super soddisfatto, finalmente quello che cercavo. Utilissimo
Ali Aljesmi –
Quick battery finish .. screen left side overheat
Antonio Aigües –
No consigo conectar con algunas maracas de cámaras de marcas reconocidas, como por ejemplo IDIS.El error que me da es Error en el usuario o contraseña, cuando las estoy poniendo correctamente.Muy complicado conectar cualquier cámara
charles ALPHONSE –
Dommage j ai du le retourner problème de bouton on / off fonctionnait une fois sur deux
