REVODATA Gigabit Micro USB PoE Splitter 5V 2.4A Output, IEEE 802.3af Standard 10,100,1000Mbps for USB Charging Cable RJ45 Port Power Over Ethernet Splitter Adapter (USB0502G Black)
£11.09
Price: £11.09
(as of Jul 12, 2025 01:27:38 UTC – Details)
Product Description
PoE Splitter, the best way to expand you smart home device, simple and cost saving.
Easy to add new device, get rid of cluttered wiring.
With more new devices added, it becomes difficult to manage the wiring. You have to install a lot of independent power adapter to power supply the Non-PoE device. But by using our PoE splitter, you will no longer need to worry about the trouble installation and cost.
The PoE splitter is powered from PoE switch, and it will break the PoE power into power(via power cable) and data(via RJ45 cable), then those Non-PoE device can use it just as PoE device. Only need a network RJ45 cable, can right to the install place, no extra power adaapter ever needed!
POE Splitter
PoE installation is very simple, low cost, not need of extra power adapter, with a lot of advantage but it is just for PoE device. But with the help of our splitter, Non-PoE device can work just as PoE device. And You can easily expand as much device as you want.
Better experience provide by Gigabit PoE splitter
Various port are available for you to choose
DC 5.5*2.1mm port mostly can be used for IP camera, wireless AP, and other device with DC port.
DC 5.5*2.5mm port also support DC 5.5*2.1mm port device, it is more flexible.
Micro USB port can be used for Raspberry Pi 3B and device powered from Micro USB port.
Type-C port, also known as USB-C, can be used for Raspberry Pi 4B and new device powered from Type-C port.
Plug & Play
Our PoE splitter is plug and play design, all you need is directly connect it to your device, and it will work immediately. Very easy to use and no configuration required.
1000Mbps
Most PoE splitter in the market is 100 mbps, sometimes may cause delay. But our PoE splitter is gigabit 1000Mbps, which is 125 MB per seconds, 10 times faster. You will no longer suffer from High Latency| Lagging| Lost Packets, gives you a better experience.
Add To Basket
Add To Basket
Add To Basket
Customer Reviews
4.4 out of 5 stars 1,362
4.4 out of 5 stars 1,362
4.5 out of 5 stars 198
4.4 out of 5 stars 1,362
4.4 out of 5 stars 1,362
4.4 out of 5 stars 1,362
Price
£12.09£12.09
— no data
£11.09£11.09
— no data
— no data
£13.39£13.39
Standard
IEEE802.3 af/at IEEE802.3 af/at IEEE802.3 af IEEE802.3 af IEEE802.3 af/at IEEE802.3 af/at
Power
Input 48V DC /0.6A, Output 12V/2A Input 48V DC /0.6A, Output 12V/2A Input 48V DC /0.35A, Output 5V/2.4A Input 48V DC /0.35A, Output 5V/2.4A Input 48V DC /0.6A, Output 5V/3A Input 48V DC /0.6A, Output 5V/3A
Gigabit
✓
✓
✓
✓
✓
✓
Interface Type
5.5*2.1mm DC 5.5×2.5mm DC Micro USB TYPE-C Micro USB TYPE-C
Raspberry Pi 3B
no data
no data
✓
no data
✓
no data
Raspberry Pi 4B
no data
no data
no data
no data
no data
✓
Safe & Stable
Built in advanced chip, offer multiple protection to protect terminal device. Over current, short circuit, over voltage, over power protection.
Wide Applications
Wide range of applications, work with IP camera for family safety, work with new samrt home device for convenience, work with AP for business.
Comply with IEEE802.3af/at standard
Comply with IEEE802.3af/at standard, auto detect then output proper power for device. Friendly for new beginner.
Specification
Transfer Rate 10/100/1000Mbps TRNF 1/2(+),3/6(-);4/5(+),7/8(-) Temperature Work within -20~50°,Storage within -30~60° Humidity Work within 10%~90% (Non-condensing), Storage within 5%~95% (Non-condensing) Dimension 27.5 x 2.8 x 2.3cm Weight 0.05kg LED Green flashes, yellow always on Package Content 1 x Gigabit POE Splitter
Quick question and answer to help you to know our product better
Question: How do I know if this product work with me?Answer: If your place or office has PoE power like PoE switch, and you’re looking for alternative power output for your Non-PoE device because you don’t want to install extra power adapter. Then our PoE splitter is work with you, it can received PoE power, and break it into DC power and Ethernet via 2 cable for your Non-PoE device.—————————————————————————-Question: Why the voltage of the PoE splitter is unstable when I test it?Answer: If Poe splitter is not connect to terminal device, means there is no load. It will trigger light load protection, and voltage will be unstable. The voltage will stable if gives 10mA, which is 0.01A load.—————————————————————————-Question: How do I know whether it work with my device or not?First confirm which power interface, what voltage and what current your device need. For IP camera, you can choose DC 5.5*2.1mm port with 12V voltage, like our PS5712G, PS5712TG, For Type-C device like Raspberry Pi, you can choose Type-C port with 5V voltage, like our TYPEC0502G, TYPEC0503G, For Micro USB device, you can choose Micro USB port with 5V voltage, like our USB0502G, USB0503G.
【PoE 48V to Micro USB 5V/2.4A】Convert 48V PoE to Micro USB 5V/2.4A output. Micro USB cable for power supply and RJ45 cable for netework transmission. Non-PoE devices with Micro USB ports can enjoy the same convenience of POE power as POE devices.
【Max 12W Output】Auto detecte, appropriate power output to connected devices. Up to Max 12W (5V/2.4A) via Micro USB connector.
【Gigabit Speed up to 1000Mbps】Support fast gigabit transmission, compatible with 10/100/1000Mbps rates.
【Plug and Play 】Simply connect to terminal equipment and work, easy to use, avoid complex configuration.
【Multiple Protection】Isolation circuit protection, Short circuit protection, Overvoltage protection, effectively protect your equipment.
